Advent of Code 2020 day 8

    It had to happen sometime! Day 8 was the first virtual machine to simulate. First off,  a couple of data structures for storing the machine (the need for the MachineResult only became apparent in part 2).

    data Instruction = Acc Int | Jmp Int | Nop Int
      deriving (Show, Eq)
    type Program = V.Vector Instruction
    data Machine = Machine
      { machineProgram :: Program
      , machineIP :: Int
      , machineAcc :: Int
    data MachineResult = Looped Int | Terminated Int | OutOfBounds Int Int
      deriving (Show, Eq)

    The fields in the Machine record are the program, the instruction pointer (location of the next instruction to execute) and the current value of the accumulator.

    Reading in the machine was simple, just reading the text and creating a program. The interesting thing was I decided to use a Vector for the program, rather than a List.

    instructionP = accP <|> jmpP <|> nopP
    accP = Acc <$> ("acc " *> signed decimal)
    jmpP = Jmp <$> ("jmp " *> signed decimal)
    nopP = Nop <$> ("nop " *> signed decimal)
    programP = V.fromList <$> sepBy instructionP endOfLine

    Part 1

    For executing the machine, I kept a separate Set of visited IPs and executed the machine one step at a time. (I did think about using some form of State or Reader monad for the machine, but decided that it wasn't worth the effort for something so simple.)

    part1 machine = executeMany S.empty machine
    executeMany visited machine
      | currentIP `S.member` visited = Looped (machineAcc machine)
      | currentIP == programSize     = Terminated (machineAcc machine)
      | currentIP > programSize      = OutOfBounds (machineAcc machine) currentIP
      | otherwise                    = executeMany visited' machine'
      where machine' = executeStep machine
            currentIP = machineIP machine
            visited' = S.insert currentIP visited
            programSize = V.length $ machineProgram machine
    executeStep m = execute ((machineProgram m)!(machineIP m)) m
    execute (Acc n) m = m { machineIP = machineIP m + 1
                          , machineAcc = machineAcc m + n
    execute (Jmp n) m = m { machineIP = machineIP m + n }
    execute (Nop n) m = m { machineIP = machineIP m + 1 }

    Part 2

    Brute force was the easiest way to go for this. I mutated the program by replacing, one at at time, the nop and jmp instructions; then I ran all the mutated programs to see which reached the "termination" condition.

    part2 program = filter terminates $ map runProgram programs
      where programs = altPrograms program
            runProgram p = executeMany S.empty (Machine p 0 0)
            terminates (Terminated _) = True
            terminates (OutOfBounds _ _) = True
            terminates _ = False
    altPrograms program = map (mutateProgram program) [0..(V.length program - 1)]
    mutateProgram program i = go (program!i)
      where go (Nop n) = program // [(i, Jmp n)]
            go (Jmp n) = program // [(i, Nop n)]
            go _ = program

    As promised, there was only one variant program that Terminated, and none that failed with an OutOfBounds condition.


    You can find the code here or on Gitlab.
