Advent of Code 2023 day 12

    Day 12 was the first time that a different algorithm was needed for part 2 (though day 5's solution came close, as it needed a different representation using the same algorithm).

    Data structures and parsing

    Not a great deal to see here. I define a new type for the springs, and a Record to record a row of the input, split between the springs and the signature.

    data Spring = Unknown | Damaged | Operational deriving (Show, Eq, Ord)
    data Record = Record [Spring] [Int] deriving (Show, Eq, Ord)

    recordsP = recordP `sepBy` endOfLine
    recordP = Record <$> (many1 springP <* " ") <*> (decimal `sepBy` ",")
    springP = (Unknown <$ "?") <|> (Damaged <$ "#") <|> (Operational <$ ".")

    Part 1

    I used a brute-force approach here, making all possible assignments of Unknown springs to Damaged or Operational, and counting how many matched the given signature.

    I could generate the signature of a set of springs (assuming all the Unknown ones have been assigned) by grouping them, finding the groups of Damaged springs, then finding the length of each of them.

    matchesSignature :: Record -> Bool
    matchesSignature (Record springs signature) = signSprings springs == signature

    signSprings :: [Spring] -> [Int]
    signSprings = fmap (length) . filter ((== Damaged) . head) . group

    Then I needed to find all possible assignments of Unknown springs. Rather than go through all 2n possible assignments, I decided to be a bit clever. The signature shows how many Damaged springs there are in total, and therefore I can tell how many Unknown springs need to be Damaged to reach that total. Therefore, I find all ways to pick that many springs from the possible ones.

    numDamagedToPlace :: Record -> Int
    numDamagedToPlace (Record springs signature) = totalDamaged - knownDamaged
      where knownDamaged = length $ filter (== Damaged) springs
            totalDamaged = sum signature

    choose :: Int -> [a] -> [[a]]
    choose 0 _ = [[]]
    choose n (x:xs)
      | length xs == n - 1 = [(x:xs)]
      | otherwise = (fmap (x:) (choose (n-1) xs)) ++ (choose n xs)

    candidates :: Record -> [[Int]]
    candidates r@(Record springs _) =
      choose (numDamagedToPlace r) (elemIndices Unknown springs)

    Once I know where to assign Unknown springs to be Damaged, I can do the assignment and use that to generate all the possible assignments for a particular record:

    replaceUnknowns :: [Spring] -> [Int] -> [Spring]
    replaceUnknowns springs indices = foldr go [] indexedSprings
      where indexedSprings = zip [0..] springs
            go (i, Unknown) acc = if (i `elem` indices) then Damaged:acc
                                                        else Operational:acc
            go (_, s) acc = s:acc

    possibleAssignments :: Record -> [Record]
    possibleAssignments r@(Record springs signature) =
      fmap (\p -> Record p signature) possibles
      where cands = candidates r
            possibles = fmap (replaceUnknowns springs) cands

    With that, I can count the number of possible assignments that match that record's signature, and apply that to all the records.

    part1 :: [Record] -> Int
    part1 = sum . fmap countViableAssignments

    countViableAssignments :: Record -> Int
    countViableAssignments = length . filter matchesSignature . possibleAssignments

    Part 2

    The above does the small examples of part 1, but fails dismally on part 2. A better approach is needed.

    The key idea is that I don't need to know how to assign the Unknown springs to be either Damaged or Operational, I just need to know how many assignments there are. If I know that for a particular Record, I can find how many assignments there are for a slightly longer Record that has this one as a suffix.

    For instance, if I have a record that looks like Record (..###..:_) (3,2,:_), it has the same number of assignments as Record (.###..:_) (3,2,:_) (having dropped the first Operational spring). Similarly, if I have a record that looks like Record (###..#:_) (3,2,:_), it has the same number of assignments as Record (.#:_) (2,:_) (having dropped the first group of three Damaged springs + the next Operational spring, and the first signature). If there are Unknown springs, I should be able to fit them into one or both of the two patterns; in that case, the number of assignments for this record is the sum of each matching pattern.

    That's a simple recursive relationship. I can turn that into a dynamic programming one by having a table that stores these intermediate results. If I build up the table from the shortest tails of the springs and signatures, each new Record I encounter will always have its suffixes in the table.

    In this case the table is a Map from Record to number of assignments.

    type Cache = M.Map Record Int

    But first, a couple of utility functions that indicate if a spring (or chunk of springs) matches that pattern I want. possibleDamagedChunk checks that the next n springs can be Damaged and the one after Operational, or the next n springs can be Damaged and there are no more.

    isPossOperational :: Spring -> Bool
    isPossOperational Operational = True
    isPossOperational Unknown = True
    isPossOperational _ = False

    isPossDamaged :: Spring -> Bool
    isPossDamaged Damaged = True
    isPossDamaged Unknown = True
    isPossDamaged _ = False

    possibleDamagedChunk :: [Spring] -> Int -> Bool
    possibleDamagedChunk springs n =
      isDamagedChunk && ((null afterChunk) || (isPossOperational $ head afterChunk))
      where isDamagedChunk = (length $ filter isPossDamaged $ take n springs) == n
            afterChunk = drop n springs

    I then go about creating the dynamic programming table. I start by filling the outer edges, where the springs or signature are null. Most of these are zero, apart from the small section of no signature and the last few springs are Operational.

    initialCache :: Record -> Cache
    initialCache (Record springs signature) = M.union lastOperational cache0
      where cache0 = M.union sprs sigs
            sprs = M.fromList $ fmap (\s -> (Record s [], 0)) $ tails springs
            sigs = M.fromList $ fmap (\g -> (Record [] g, 0)) $ tails signature
            lastOperationalChunk =
              reverse $ takeWhile isPossOperational $ reverse springs
            lastOperational =
              M.fromList $ fmap (\s -> (Record s [], 1)) $ tails lastOperationalChunk

    I fill the table first by taking each suffix of the springs; for each, I take each suffix of the signatures; for each particular combination of spring and suffix, I find the number of arrangements by looking up the values in the two relevant table cells already found.

    fillTable, fillTableSigs, fillTableCell :: Cache -> Record -> Cache
    fillTable table (Record springs signatures) =
      foldr (\ss t -> fillTableSigs t (Record ss signatures)) table $ tails springs

    fillTableSigs table (Record springs signatures) =
      foldr (\gs t -> fillTableCell t (Record springs gs)) table $ tails signatures

    fillTableCell table record
      | record `M.member` table = table
      | otherwise = M.insert record (opN + signN) table
      where (Record springs@(s:ss) signatures@(g:gs)) = record
            opN = if (isPossOperational s) then table M.! (Record ss signatures) else 0
            signN = if (possibleDamagedChunk springs g) then table M.! (Record (drop (g + 1) springs) gs) else 0

    Once the table is full, I can find the number of possible arrangements by looking up the full record in the table.

    countViable :: Record -> Int
    countViable record = table M.! record
      where table0 = initialCache record
            table = fillTable table0 record

    Unfolding the record is a combination of replicate and intercalate.

    unfoldRecord :: Record -> Record
    unfoldRecord (Record springs signature) = Record uSprings uSignature
      where uSprings = intercalate [Unknown] $ replicate 5 springs
            uSignature = concat $ replicate 5 signature

    and the two parts are solved:

    part1, part2 :: [Record] -> Int
    part1 = sum . fmap countViable
    part2 = sum . fmap (countViable . unfoldRecord)

    Code

    You can get the code from my locally-hosted Git repo, or from Gitlab.
