Advent of Code 2021 day 12

    Day 12 had some fiddly bits, so things ended up fairly complex. In essence, the problem is an exhaustive search for paths on a graph, but the rules on revisiting nodes makes for complex code. In addition, the extension task for part 2 was such that it ended up easier to solve part 2 first, then extract just the solutions that were valid for part 1.

    As with all search-type tasks, I find it easier to think about the problem as having an agenda of partial paths, with the agenda being updated as the search progresses.

    In this case, an agendum was represented as a Path containing the current cave, the history of all caves visited, the closed set of small caves visited, and an optional record of a small cave that was visited twice.

    data Path = Path String         -- current cave
                     [String]       -- caves visited
                     (S.Set String) -- closed set of small caves visited
                     (Maybe String) -- the small cave we've visited twice
      deriving (Eq, Ord, Show)


    The allPaths function finds all the paths in the cave complex. It takes as input the graph (the cave complex), a Set of partial Paths, and a Set of the completed routes found so far. It extracts an arbitrary element of the agenda, extends it if possible, then adds the extended paths back into the agenda. If the path ends at the end cave, the path is added to the set of results.

    allPaths :: Graph -> PathSet -> PathSet -> PathSet
    allPaths graph agenda results
      | S.null agenda = results
      | otherwise = allPaths graph agenda'' results'
      where (current, agenda') = S.deleteFindMin agenda
            newPaths = extendPath graph current
            agenda'' = S.union agenda' newPaths
            results' = S.union results $ recordResult current

    recordResult :: Path -> PathSet
    recordResult path@(Path current _ _ _)
      | current == "end" = S.singleton path
      | otherwise = S.empty


    All the tricky details are handled in extendPath. It's given a Path and returns a Set of new Paths that lead on from it. There are a lot of things to check, so the logic here needs some explanation.

    1. If the path gets as far as "end", there are no extensions.
    2. If the path has returned to "start" (the current cave is "start" and "start" is in the visited set), there are no extensions.
    3. Othewise, there are extensions.

    There are two types of extension:

    1. Visting a cave not in the visited closed set
    2. Visiting a cave in the visited set, but we've not revisited a small cave yet.

    To handle the first case, I find all the neighbours of the current cave, remove all the ones in visited, and create a new Path for each.

    To handle the second case, I check that we've not already used our "return to a small cave" exemption (returned == Nothing), then extend the path for every reachable small cave we've already visited.

    In both cases, I update visited if I'm currently in a small cave.

    It's a fiddly mess.

    extendPath :: Graph -> Path -> PathSet
    extendPath graph (Path current trail visited returned)
      | current == "end" = S.empty
      | (current == "start") && (current `S.member` visited) = S.empty
      | otherwise = S.union (S.map newPathNovel visitableNovel)
                            (S.map newPathReturning visitableReturning)
      where neighbours = graph ! current
            visited' = if isSmall current then S.insert current visited else visited
            trail' = (current:trail)
            visitableNovel = neighbours \\ visited -- if we're not returning to a small cave
            visitableReturning = if returned == Nothing
              then (S.filter isSmall neighbours) `S.intersection` visited -- returning to a small cave already visited
              else S.empty
            newPathNovel next = Path next trail' visited' returned
            newPathReturning next = Path next trail' visited' (Just next)


    That's the solution to part 2. The solution to part 1 is the same, only without the paths that take advantage of the "revisit a small cave" allowance.

    main :: IO ()
    main =
      do  text <- TIO.readFile "data/advent12.txt"
          let edges = successfulParse text
          let graph = mkGraph edges
          let paths = allPaths graph (S.singleton (Path "start" [] S.empty Nothing)) S.empty
          print $ part1 paths
          print $ part2 paths

    mkGraph :: [(String, String)] -> Graph
    mkGraph edges = foldr mkEdge pass1 $ map swap edges
      where pass1 = foldr mkEdge M.empty edges
            mkEdge (here, there) = M.insertWith (S.union) here (S.singleton there)

    part1 :: PathSet -> Int
    part1 paths = S.size $ S.filter nonReturning paths

    part2 :: PathSet -> Int
    part2 paths = S.size paths


    nonReturning :: Path -> Bool
    nonReturning (Path _ _ _ Nothing) = True
    nonReturning (Path _ _ _ (Just _)) = False


    Code

    You can get the code from my locally-hosed Git repo, or from Gitlab.
